OE F00002-FA-AI-JN2-SER

Test SERIAL ENCODERS for Fanuc Ai Servo Motors using the OE F00002-FA-AI-JN2-SER Feedback Cable with 10 Position JN2 JAE Connector by Octava Engineering.

Series Compatibility:

  • Alpha i
-
+

1 In Stock

Brand Compatibility: Fanuc

Use this Test Cable to test the following types of motors and encoders with the Linea X3.

Feedback Compatibility Motor Compatibility
A860-2000-T301 [aiA1000] A860-2001-T321 [aiA16000] ai xx/xxxx bis xx/xxxx
A860-2001-T301 [aiA16000] A860-2005-T321 [aiI1000] aiC xx/xxxx A06B-0xxx-Bxxx
A860-2005-T301 [aiI1000] A860-2020-T321 [biA128] aiF xx/xxxx A06B-0xxx-Bxxx#xxxx
A860-2010-T341 [aiAR128] aiM xx/xxxx aiF xx/xxxxHV
A860-2020-T301 [biA128] ais xx/xxxx ais xx/xxxxHV
A860-2014-T301 [aiA64] aisR xx/xxxx bis xx/xxxxHV
A860-2000-T321 [aiA1000] bi xx/xxxx

Connects:
Linea X3
Encoder
Tester
-
Material:
• 8 Pair Flex Cable
• 24 AWG [19x36] PVC Ins.
• Foil Shield w/ Drain
• Matte Blue PVC Outer Jacket
Cable:
Feedback
-
Standards:
• UL2464
• ROHS
Feedback:
• Absolute
• Incremental
Connector:
Mfr. JAE
P/N: JN2FS10SLK-R
Interface:
Serial
Length: 5 ft.
Custom Length Upon Request
